PLEASE NOTE: THIS ITEM IS LIKELY TO BE OUT OF STOCK FOR SEVERAL MONTHS DUE TO AER RE-LOCATING THEIR FACTORY IN GERMANY.
A new member within the Compact family. A new discrete power amp design for additional dynamic headroom. A new speaker configuration for additional tonal range and the continuation of the well–proven features and functionality of the Compact 60.
• 2-way speaker system
• Twin-channel, 3 and 2 band EQ
• 4 digital e! ect presets (reverb and delay)
• 10,60 kg (23.30 lbs)
acoustic
Compact XL solutions
advanced level
Inputs
channel 1 6.3 mm (1/4”) input jack socket as high impedance
line input stage with pad (high/low
attenuation) and switchable 9 V phantom
power, gain control.
channel 2 combined XLR/6.3 mm (1/4”) input jack socket
as high-quality line- or balanced microphone
input stage 48 V phantom power,
gain control.
Tone Controls
equalizer three band tone controls for channel 1 and
two band tone controls for channel 2
colour ‘mid-cut-treble-boost’-fi lter
effect digital effect processor with 4 presets:
1 – 3= reverb and 4= delay.
Power
power amp 200 W / 8 ohms, dynamic control
analogue signal subsonic fi lter, low distortion processing RMS limiter
Speaker System 2-way system, 8” (200 mm) polypropylen
low-midrange + 1” dome tweeter, lightweight
neodymium alloy magnets ground lift, switchable 9 V phantom power,
adjust-able aux in, footswitch (effects on/
off), tuner, line out, adjustable DI-out, send/
return, headphones
Accessories
padded gigbag
Specs
cabinet 15 mm (0.59”) finnish birch plywood
fi nish waterbased acrylic, black spatter fi nish
dimensions 325 mm x 330 mm x 285 mm
(12.80“ x 13.00“ x 11.22“), HxWxD
weight 10,60 kg (23.30 lbs)
Compact XL
input high gain bass middle treble input gain bass treble pan select level master
low
clip colour line
mic
clip
channel 1 channel 2 effect
