Digitech Whammy DT
Classic pitch shifting with drop and raised tuning
Introducing a new addition to the DigiTech Whammy Family — Whammy DT! We've taken the premier pitch shifting effects pedal added drop tuning and true bypass to bring you the ultimate Whammy pedal, the Whammy DT. With the Whammy DT, you can modify your tuning without having to change guitars or pause awkwardly to make adjustments for the next song. Key changes are at the tips of your toes and take just moments, which is crucial when the audience is feeling your vibe. Pitch shifting effects really help your guitar performance stand out and the Whammy pedal has been the core pitch shifting effect for famous artists for over 20 years. Now add full drop and raised tuning in addition to classic Whammy shifting to your effects arsenal and find out why the Whammy DT is the premiere pitch shifting effects pedal for every guitarist.
Item# WHAMMYDTV-01
General Specifications
D/A Conversion24 bit
Pitch Bend Range+2/-3 Octaves
Detune Range-4 to -30 cents
Drop Tune Range1-7 Semitones, Octave, Octave + Dry
Power Consumption2.6 Watts (< 288 mA @ 9 VDC)
Power Adapter9 VDC External Adapter
Sample Rate44.1 kHz
Frequency Response20 Hz to 20 kHz
Signal to Noise Ratio> -105 dB (A weighted); ref = max level, 22 kHz bandwidth
THD0.004% @ 1 kHz; ref = 1 dBu w/ unity gain
Dimensions
Height2.36"
Width8.2"
Depth7.73"
Audio Output
Output Type1/4” Unbalanced TS
Max Output Level+10 dBu
Output Impedance1 kΩ
Audio Input
Instrument Input Type1/4” Unbalanced TS
Max Input Level+5 dBu
Input Impedance1 MΩ
MIDI Input5-Pin Din
Footswitch Input1/4” TRS – for use with optional FS3X Footpedal
1 x Whammy DT Pedal
1 x Power Supply
