Model: P-03E Recording Series
With Matrix Infinity Pickup: P-03E
TYPE : Parlour
MATERIAL
TOP : Solid Sitka Spruce
BACK AND SIDES :Solid Mahogany
NECK : Mahogany
FINGERBOARD : Ebony
FRETS : 18
BINDING : Maple
NUT : Bone
SADDLE : Bone
ROSETTE :Herringbone
INLAY : Pearl dots
BRIDGE : Ebony
BRIDGE PINS : Composite With Dots
MACHINE HEADS : Larrivee
PICKUPS : Fishman Undersaddle
PICKGUARD : Tortoiseshell Celluloid
FINISH : Satin Polyurethane
STRINGS : 12-53 Phosphor Bronze
CASE : Hardcase
STRAP BUTTON : Lower Only
SPECS
OVERALL LENGTH : 917mm
BODY LENGTH : 454mm
LOWER BOUT : 332mm
WAIST : 200mm
DEPTH : 100mm
SCALE LENGTH : 612mm
NUT WIDTH : 44.67mm
STRING SPACING NUT : 39.19mm
AVERAGE STRING SPACING NUT : 7.48mm
STRING SPACING SADDLE : 57.07mm
AVERAGE STRING SPACING SADDLE : 11.10mm
FINGERBOARD RADIUS : 18″
NECK THICKNESS @1ST FRET : 21.38mm
NECK THICKNESS @ 10TH FRET : 24.38mm
SOUNDHOLE DIAMETER : 90.83mm
