Record the entire band.
PreSonus was a pioneer in high-channel-count audio interfaces and has spent the last 20 years listening to our customers and creating the best audio interfaces for recording large sessions. The Studio 1824c provides amazing sound-quality with eight of PreSonus’ lauded XMAX analog mic preamps onboard and pristine 24-bit 192 kHz conversion. Add two low-noise instrument preamps, balanced line level inputs, and an ADAT input to add 8 more channels whenever you need them and you have an audio interface ready to record just about any session. A complete, all-in-one recording package, Studio One® Artist music production software is included with the Studio 1824c, offering unlimited tracking with tight control-room integration.
Superior sound.
The Studio 1824c operates at up to 192 kHz for ultra-high-definition recording and mixing. High-quality converters on every input and output and eight of PreSonus’ professional-grade XMAX mic preamps enable you to capture complex musical harmonics smoothly and naturally, with no audible distortion. XMAX mic preamps are known the world over for their ability to deliver incredibly high headroom, deep lows, smooth highs, and a rich overall sound so you’ll hear every breath, transient, and detail in your recordings.
World-class recording software included.
Seamlessly integrated with the included PreSonus UC Surface control software for macOS®, Windows®, iPad®, and Android™ tablet and Studio One Artist music production software, the Studio 1824c audio interface works with virtually all macOS and Windows recording software. Easy to learn, Studio One enables you to compose, record, and produce without getting distracted by the tools. Need a new loop or sample for your latest production? Studio One lets you shop, audition, and purchase new content right from your production environment—including powerful extensions for Studio One like the CTC-1 Console Shaper and Presence XT Editor.
Stress-free recording.
Professional tools make any job easier. That’s why we included professional input and output metering on the Studio 1824c, allowing you to keep an eye on your input and mix levels while running your session. Easy-to-use DSP monitor mixing lets you create four discrete near-zero latency monitor mixes, enough for even the largest ensembles. All line-level outputs are also DC coupled, enabling them to send control voltages. Front-panel Mute, Mono, and level controls let you keep a hold of your main mix.
Wherever the sound takes you.
Whether you're upgrading your studio or building a new space for your band to record, the Studio 1824c has you covered with superior mic preamps, expandable inputs, and powerful, easy-to-use onboard monitor mixing to give you the world-class results you want. While it’s a perfect companion for any recording software, the Studio 1824c and included Studio One Artist provide you with a complete, affordable recording solution that will make you sound great.
Make your own magic.
At PreSonus, we want to make sure that our audio interfaces come with everything you need to craft your own mesmerizing spells in the studio. That’s why we include Studio One Artist with every audio interface product we make. But here in Louisiana, we have a word: lagniappe. It means "a little something extra," and it’s in that spirit that we also include the Studio Magic Suite of software with our audio interface products.
The 2020 Studio Magic is a major step up from the 2019 edition, and includes Ableton Live Lite, tutorials from Melodics, 6 virtual instruments, and 9 effects plug-ins in VST, AU, and AAX formats… all unlocked for use inside Studio One Artist with a retail value of over $1000 (US).
Features
Input/Output
Up to 18 inputs/20 outputs simultaneously (8×8 at 192 kHz)
2 mic/instrument/line inputs with XMAX Class A mic preamps
6 mic/line inputs with XMAX Class A mic preamps
8 channels of ADAT Optical I/O (4 channels at 96 kHz)
2 balanced ¼” TRS main outputs
DC coupled for sending control voltages
8 balanced ¼” TRS line outputs for monitor mixing
DC coupled for sending control voltages
2 stereo headphone outputs with individual level controls
MIDI In/Out
Stereo S/PDIF digital I/O
1 USB-C™ compatible 2.0 port
USB-C™ to USB-C™ and USB-C™ to USB-A cables included for compatibility with most computers
BNC word clock output
Integrated Software
Studio One® Artist for Mac® and Windows®
UC Surface control software for Mac, Windows, iPad®, and Android™
Studio Magic Plug-in Suite
Meters, Controls, and Features
18×8 onboard DSP monitor mixer
Front-panel level controls for main outputs
Mono and Mute buttons for the main outputs
True +48V phantom power for condenser microphones (global)
10 ladder-style 8-LED level meters (8 input, 2 main output)
Digital
USB-C™ compatible port (USB 2.0)
24-bit resolution
44.1, 48, 88.2, 96, 176.4, and 192 kHz sampling rates
Physical
1U rack-mountable
Road-rugged construction with all-metal chassis and metal knobs
Computer system requirements:
Mac
macOS® 10.11 or higher (64-bit only)
Intel® i-series 2 GHz multicore processor (or AMD equivalent) or faster
4 GB RAM (8 GB or more recommended)
Windows
Windows® 7 x64 SP1 + platform update, Windows 8.1 x64, Windows 10 x64
Intel i-series 2 GHz multicore processor (or AMD equivalent) or faster
4 GB RAM (8 GB or more recommended)
Mac and Windows Systems
USB-C™ or USB-A 2.0 port compatiblity
32 GB hard disk space
PreSonus Universal Control 2.0 or higher
Monitor with 1366×768 resolution (high-dpi monitor recommended)
Multitouch-enabled monitor required for touch operation
iOS
iOS 10 or later
iPad Pro, iPad Air 2, iPad Air, iPad mini 4, iPad mini with Retina display, iPad (4th generation) (UC Surface)
Android
Android™ 5.0 (Lollipop) or later
Android tablet (8-inch) with 1024×768 resolution (UC Surface)
Technical Specifications
General
Sample Rates 44.1, 48, 88.2, 96, 176.4, 192 kHz
Converter Resolution 24-bit
Converter Dynamic Range 114 dB
Converter Dynamic Range 114 dB
Microphone Inputs
Maximum Level +16 dBu, min gain
Gain Range 80 dB
Frequency Response 20 Hz – 20 kHz (unity gain)
Dynamic Range 110 dB (A-wtd, min gain)
THD + N 0.005% (1 kHz, 0dBu, unity gain)
EIN -128 dBu (A-wtd, 20 kHz BW, Rs=150Ω, max gain)
Input Impedance 1400Ω
Phantom Power 48V (>10 mA per channel)
Line Inputs
Maximum Level +21 dBu (balanced, min gain)
Gain Range 40 dB
Frequency Response 20 Hz-20 kHz (unity gain)
Dynamic Range 112 dB (A-wtd, min gain)
THD + N 0.005% (1 kHz, +18 dBu, min gain)
Input Impedance 10 kΩ
Instrument Inputs
Maximum Level +15 dBu (unbalanced, min gain)
Gain Range 80 dB
Frequency Response 20 Hz – 20 kHz (min gain)
Dynamic Range 112 dB (A-wtd, min gain)
THD + N 0.020% (1 kHz, +10 dBu, min gain)
Input Impedance 1M Ω
Main Outputs
Type ¼" TRS female, DC Coupled
Maximum Level +18 dBu, balanced
Frequency Response 20Hz – 20kHz (unity gain)
Dynamic Range 108 dB (A-wtd, unity gain)
THD + N 0.004% (1 kHz, -1 dBFS, unity gain)
Line Outputs
Type ¼" TRS female, DC coupled
Maximum Level +18 dBu, balanced
Frequency Response 20 Hz – 20 kHz
Dynamic Range 108 dB (A-wtd, -60 dBFS)
THD + N 0.004% (1 kHz, -1 dBFS, unity gain)
Headphone Outputs
Maximum Power 150 mW/channel (60Ω load)
Frequency Response 20 Hz – 20 kHz (unity gain)
Dynamic Range 103 dB (A-weighted, 1 kHz, unity gain)
THD + N 0.250% (1 kHz, 150 mW, unity gain)
Impedance Working Range 32Ω to 600Ω
Physical
Height 1.75" (44 mm)
Width 19" (483 mm)
Depth 5.5" (140 mm)
Weight 4.8 lbs (2.2 kg)
