Fender Blues Deluxe™ Reissue, 230V UK
Model #: 2232204000
Description
The reissue Blues Deluxe™ is a vintage-style tube amp with boutique tone at a great price that many pro rock, country and blues players have used to superb effect. While its newer cousin, the Hot Rod Deluxe™, has many modern refinements, more and more enthusiasts continue to request the warm tone, unique circuitry, classic features and sharp look of the original version. It pumps 40 watts into a single 12″ Special Design Eminence® speaker fueled by two 6L6 Groove Tubes® output tubes and three 12AX7 preamp tubes. Its two channels (normal with bright switch, and drive) are voiced for classic blues, country and rock; other features include Fender® spring reverb, effects loop, two-button channel footswitch, tweed covering, chicken head knobs and chrome control panel.
Features
40 watts
12″ Eminence® Special Design speaker
Dual channels: Normal and Drive
Classic Fender tweed look
Effects loop, bright switch and Fender spring reverb
Two-button footswitch included
Specs
Accessories
Footswitch
2-Button (Drive Select, Reverb On/Off), P/N: 0994056000 (Included)
Electronics
Channels
Two – Selectable
Connection Type
1/4″
Control Panel
Presence, Reverb, Master Volume, Middle, Bass, Treble, Drive Select Switch, Drive Volume, Bright Switch
Controls
Presence, Reverb, Master Volume, Middle, Bass, Treble, Drive Select Switch, Drive Volume, Bright Switch
Effects Loop
1/4″ (Send/Return)
Inputs
Two – (1/4″, Input 2 operates at -6dB)
Wattage
40 Watts
General
Amplifier Type
Tube
Color
Tweed
Platform
Pro Tube
Product Name
Blues Deluxe™ Reissue, 230V UK
Series
Hot Rod
Hardware
Amplifier Covering
Tweed
Amplifier Jewel
Red Jewel
Cabinet Material
3/4” Particle Board with Plywood Baffle Board
Control Knobs
Chicken-Head Style Pointer – Black
Front Panel
Chrome
Grille Cloth
Vintage-Style Brown and Gold
Handle
Molded Rubber “Dog Bone” Style
Reverb Tank
4EB3C1B (p/n 0050394049)
Reverb Tank Type
4EB3C1B (p/n 0050394049)
Speaker Jack
Two 1/4″ Parallel (Internal and External)
Measurements
Power Tubes
2 x 6L6
Product Depth
10.4375″ (265 mm)
Product Height
18.75″ (47.6 cm)
Product Width
23.5″ (59.7 cm)
Miscellaneous
Commodity Code
8518.40.2000
Power Cable
Non-IEC
Speakers
Speakers
One – 12″ Eminence® Special Design
Total Impedance
8 ohms
Tubes
Power Tubes
2 x 6L6
Preamp Tubes
3 x 12AX7
Rectifier
Solid State
