2-way bass-reflex bi-amplified nearfield studio monitor with 6.5" cone woofer and 1" dome tweeter.
- 2-way bass-reflex bi-amplified nearfield studio monitor with 6.5" cone woofer and 1" dome tweeter
- 43Hz – 30kHz frequency response
- 60W LF plus 35W HF bi-amp system for high-performance 95W power amplification
- ROOM CONTROL and HIGH TRIM response controls
- XLR and TRS phone jack inputs accept balanced or unbalanced signals
Specs
General specifications
Speaker type | 2-way bi-amp powered studio monitor | |
---|---|---|
Frequency range (-10dB) | 43Hz – 30kHz | |
Components | LF | 6.5" cone |
HF | 1" dome | |
Crossover | 2kHz | |
Output power | 95W (LF:60W, HF:35W) | |
I/O connectors | XLR3-31 type (balanced), PHONE (balanced) | |
Power consumption | 55W | |
Shape | Bass-reflex type | |
Cabinet material | MDF | |
Dimensions | W | 210mm (8.3") |
H | 332mm (13.1") | |
D | 284mm (11.2") | |
Net weight | 8.2kg (18.1 lbs.) | |
Others | LEVEL control (+4dB/center click) , EQ: HIGH TRIM switch (+/- 2dB at HF) / ROOM CONTROL switch (0/-2/-4 dB under 500Hz) |
