- Produces extreme, low-end distortion for modern metal and hard rock
- Gain Boost circuit creates huge distortion and sustain regardless of level
- New Bottom control for bottom-heavy distortion matched to 6- or 7-string guitars
- Tone control adjusts balance between high and low frequencies
-
Boss 5-year warranty
Specs
- Nominal Input Level
- -20 dBu
- Input Impedance
- 1 M ohms
- Nominal Output Level
- -20 dBu
- Output Impedance
- 1 k ohms
- Equivalent Input Noise Level
- -110 dBu (IHF-A, Typ.)
- Controls
- Pedal Switch, GAIN BOOST Knob, DIST (distortion) Knob, TONE Knob, BOTTOM Knob, LEVEL Knob
- Indicator
- CHECK Indicator (Serves also as battery check indicator)
- Connectors
- INPUT Jack, OUTPUT Jack, AC Adaptor Jack (DC 9 V)
- Power Supply
- DC 9 V: Dry battery, AC Adaptor (PSA-series: optional)
- Current Draw
- 18 mA (DC 9 V)
- Accessory
- Dry battery (9 V type) S-006P/9 V (6F22/9 V)
- Option
- AC Adaptor: PSA-series
- Size and Weight
- Width
- 73 mm
- 2-7/8 inches
- Depth
- 125 mm
- 4-15/16 inches
- Height
- 55 mm
- 2-3/16 inches
- Weight
- 0.4 kg
- 0 lbs. 15 oz.
-
