Charvel PRO-MOD SO-CAL STYLE 1 HH FR M
2966002503 / GAMERA BLACK
Designed to inspire and with four decades of experience, the Charvel® Pro-Mod So-Cal Style 1 HH FR M is a slick performer with modern features and versatile sound every guitarist will appreciate. Born from a love of high-speed playing and So-Cal style, this high-octane axe is packed with the classic playability and innovative design elements that have made Charvel a legendary name in high performance.
More comfortable than an overstuffed armchair, the Pro-Mod So-Cal Style 1 HH FR M is sleekly sculpted out of alder and coupled with a rock-solid bolt-on maple neck with a pair of graphite-reinforcement rods to handle the ravages of the road and climate. A conveniently located heel-mount spoke wheel allows for rapid truss rod tweaks, even in between songs. Engineered for effortlessly nimble playing, the speed neck profile and 12”-16” compound radius maple fingerboard with 22 frets is perfect for all styles of play – from low end riffing to soaring leads with worry-free upper-register bends.
Hot-rodded for unparalleled performance and sound, this instrument hosts a high-output Seymour Duncan® Distortion TB-6 humbucking bridge pickup and a warm, fat Seymour Duncan Distortion SH-6N humbucking neck pickup. The volume control hides a push/pull coil split for even more highly useful tonal variations, ideal for everything from a biting lead sound to thick, chunky rhythm work. The no-load tone control operates like a standard tone control from positions one through nine, removing itself from the circuit at position ten for transparent sound that lets the full natural voice of the guitar shine through. The Floyd Rose® 1000 Series double-locking tremolo bridge system allows players to scream and rumble without sacrificing tuning stability.
- ALDER BODY
- BOLT-ON MAPLE NECK WITH GRAPHITE REINFORCEMENT
- 12″-16″ COMPOUND RADIUS MAPLE FINGERBOARD
- UNIQUE CHARVEL BACK NECKSHAPE
- SEYMOUR DUNCAN® DISTORTION™ TB-6 & SH-6N PICKUPS
- 3-WAY BLADE, PUSH/PULL VOLUME & NO-LOAD TONE CONTROLS
- HEEL-MOUNT TRUSS ROD ADJUSTMENT WHEEL
- FLOYD ROSE®1000 SERIES DOUBLE-LOCKING TREMOLO BRIDGE SYSTEM
- THREE-PLY TORTOISESHELL PICKGUARD
GENERAL
Model Number 2966002503
Series Pro-Mod
Color Gamera Black
Number of Strings 6
Orientation Right-Hand
ELECTRONICS
Bridge Pickup Seymour Duncan® Distortion™ TB-6
Neck Pickup Seymour Duncan® Distortion™ SH-6N
Pickup Color Black
Controls Volume (Push/Pull Coil Split), No-Load Tone
Pickup Switching 3-Position Blade: Position 1. Bridge Pickup, Position 2. Both Inner Coils, Position 3. Neck Pickup – (Split Engaged) – Position 1. Bridge Outer Coil, Position 2. Both Outer Coils, Position 3. Neck Outer Coil
Pickup Configuration HH
BODY
Body Finish Gloss
Body Shape So-Cal Style 1
Body Material Alder
HARDWARE
Bridge Floyd Rose® 1000 Series Double-Locking Tremolo (Recessed)
Hardware Finish Chrome
Tremolo Arm Floyd Rose® 1000 Series Locking
Tuning Machines Charvel®-Branded Die-Cast
Pickguard 3-Ply Tortoiseshell
Control Knobs Knurled Flat-Top
Switch Tip Black
Saddle Height Wrench N/A
NECK
Neck Material Maple
Neck Construction Bolt-On with Graphite Reinforcement
Neck Finish Hand-Rubbed Satin Urethane
Neck Shape Speed Neck with Rolled Fingerboard Edges
Neck Binding None – Rolled Fingerboard Edges
Scale Length 25.5″ (64.77 cm)
Fingerboard Radius 12″-16″ Compound Radius (304.8 mm to 406.4 mm)
Fingerboard Material Maple
Number of Frets 22
Fret Size Jumbo
Nut Material Floyd Rose® 1000 Series Locking
Nut Width 1.6875″ (42.86 mm)
Position Inlays Black Dot
Side Dots Black
Truss Rod Nut Heel-Mount Truss Rod Adjustment Wheel
String Trees Floyd Rose® Retainer Bar
Headstock Licensed Fender® Stratocaster®
Neck Plate 4-Bolt Serialized
MISCELLANEOUS
Strings Nickel Plated Steel (.009-.042 Gauges)
Strap Buttons Standard
